HydroMinder WDP
Water-Driven Pump for car wash, dilution range (500:1 to 20:1), up to 11 GPM
The HydroMinder name has been well-known in the vehicle wash market space for many years, and now Hydro Systems is expanding its water-driven pump (WDP) product line for use in this industry. HydroMinder WDP is designed for use with the most common chemicals throughout all phases of the vehicle wash cycle. It couples outstanding chemical resistance with the ability to last 62 million cycles prior to maintenance.
Markets
Applications
Vehicle Chemical Dilution Nutrient Delivery Line Cleaning Solutions Chemical Delivery
Exceeds 62 million cycles before maintenance
Toolfree maintenance reduces repair time by 50%
Adjustable lower ends allow for multiple chemistries to be used with one unit reducing total cost of ownership
HydroMinder WDP Resources
Everything you need all in one place
Longer lasting life
Not only is the HydroMinder WDP water-driven pump specifically engineered to accurately inject chemistry into water, it lasts up to 62 million cycles before maintenance is required. The pump's advanced chemical resistance allows the pump to last longer in applications where aggressive chemicals are present.
Tool-free maintenance is a standard feature
HydroMinder WDP can be repaired without the need for tools. This water-driven pump can be repaired up to 50% less time compared to other water-driven pumps.
The same pump can be used with multiple lower ends
The ability to use the same pump with different lower ends allows the user to switch between different dilution ratios without having to buy a new pump.
5.00 Injector Repair Parts
| HydroMinder WDP Model | Part # NPT/GHT | Part # BSP | Flow Rate | Injection Rate | Operating Pressure | Approximate Dimensions | Weight | Water Capacity Per Cycle |
| Adjustable 2% Model | HYD117947CW | HYD117957CW | 0.02 - 11 GPM 5 - 2500 L/hr. | 1:500 - 1:50 0.2 - 2% | 5 - 90 psi 0.3 - 6.2 bar | 15” (38.1 cm) tall 6.5” (16.5 cm) wide 5.25” (13.3 cm) deep | 2.62 lbs. 1.19 kg. | 12.8 oz. 0.38 L |
| Adjustable 5% Model | HYD117948CW | HYD117958CW | 0.02 - 11 GPM 5 - 2500 L/hr. | 1:128 - 1:20 0.8 - 5% | 5 - 90 psi 0.3 - 6.2 bar | 15” (38.1 cm) tall 6.5” (16.5 cm) wide 5.25” (13.3 cm) deep | 2.62 lbs. 1.19 kg. | 12.8 oz. 0.38 L |
| KEY | PART NO. | DESCRIPTION |
| 1 | HYD011732 | Kit M - Mounting bracket kit |
| 2 | HYD017200XT | Kit H - Motor piston replacement |
| 3 | HYD102601NPT | Body, NPT, PVDF, AquaBlend Xtreme |
| HYD102601BSP | Body, BSP, PVDF, AquaBlend Xtreme |
| KEY | PART NO. | DESCRIPTION |
| 1 | HYD017210CW | Kit A: Dosage gasket kit |
| 2 | HYD017211CW | Kit B: Wear kit |
| 3 | HYD017213CW | Kit D: Check valve kit |
| 4 | HYD017214CW | Kit E: Wear parts maintenance kit |
| 5 | HYD017216CW | Kit G: Complete lower end kit |
| KEY | PART NO. | DESCRIPTION |
| 1 | HYD017220CW | Kit A: Dosage gasket kit |
| 2 | HYD017221CW | Kit B: Wear kit |
| 3 | HYD017223CW | Kit D: Check valve kit |
| 4 | HYD017224CW | Kit E: Wear parts maintenance kit |
| 5 | HYD017226CW | Kit G: Complete lower end kit |
Longer lasting life
Not only is the HydroMinder WDP water-driven pump specifically engineered to accurately inject chemistry into water, it lasts up to 62 million cycles before maintenance is required. The pump's advanced chemical resistance allows the pump to last longer in applications where aggressive chemicals are present.
Tool-free maintenance is a standard feature
HydroMinder WDP can be repaired without the need for tools. This water-driven pump can be repaired up to 50% less time compared to other water-driven pumps.
The same pump can be used with multiple lower ends
The ability to use the same pump with different lower ends allows the user to switch between different dilution ratios without having to buy a new pump.
5.00 Injector Repair Parts
| HydroMinder WDP Model | Part # NPT/GHT | Part # BSP | Flow Rate | Injection Rate | Operating Pressure | Approximate Dimensions | Weight | Water Capacity Per Cycle |
| Adjustable 2% Model | HYD117947CW | HYD117957CW | 0.02 - 11 GPM 5 - 2500 L/hr. | 1:500 - 1:50 0.2 - 2% | 5 - 90 psi 0.3 - 6.2 bar | 15” (38.1 cm) tall 6.5” (16.5 cm) wide 5.25” (13.3 cm) deep | 2.62 lbs. 1.19 kg. | 12.8 oz. 0.38 L |
| Adjustable 5% Model | HYD117948CW | HYD117958CW | 0.02 - 11 GPM 5 - 2500 L/hr. | 1:128 - 1:20 0.8 - 5% | 5 - 90 psi 0.3 - 6.2 bar | 15” (38.1 cm) tall 6.5” (16.5 cm) wide 5.25” (13.3 cm) deep | 2.62 lbs. 1.19 kg. | 12.8 oz. 0.38 L |
| KEY | PART NO. | DESCRIPTION |
| 1 | HYD011732 | Kit M - Mounting bracket kit |
| 2 | HYD017200XT | Kit H - Motor piston replacement |
| 3 | HYD102601NPT | Body, NPT, PVDF, AquaBlend Xtreme |
| HYD102601BSP | Body, BSP, PVDF, AquaBlend Xtreme |
| KEY | PART NO. | DESCRIPTION |
| 1 | HYD017210CW | Kit A: Dosage gasket kit |
| 2 | HYD017211CW | Kit B: Wear kit |
| 3 | HYD017213CW | Kit D: Check valve kit |
| 4 | HYD017214CW | Kit E: Wear parts maintenance kit |
| 5 | HYD017216CW | Kit G: Complete lower end kit |
| KEY | PART NO. | DESCRIPTION |
| 1 | HYD017220CW | Kit A: Dosage gasket kit |
| 2 | HYD017221CW | Kit B: Wear kit |
| 3 | HYD017223CW | Kit D: Check valve kit |
| 4 | HYD017224CW | Kit E: Wear parts maintenance kit |
| 5 | HYD017226CW | Kit G: Complete lower end kit |
Ready to get started?
Our experts are here to help. Tell us more about what you need
so we can connect you to the right Hydro experts.
Common Questions
Have a different question? Reach Out
HydroMinder WDP has been designed for use with various chemistries ranging from low, neutral, to high pH used in vehicle wash applications. Example chemistries can be found on the data sheet.
No. The product is only available with adjustable lower ends.
1:500 or 0.2%.
1,500 cP
NPT/GHT and BSP connections.
